    High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing

    Ask Lasest Price
    Brand Name : Beli
    Model Number : YX65-225-675
    Certification : CE
    Price : USD 38000-45000 / set
    Payment Terms : T/T, L/C
    Supply Ability : 20 sets/ Month
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    High Speed Steel Deck Roll Forming Machine For Closed Floor Decks Producing

    Roll Forming Machine For Closed Floor Decking


    Description:


    This Metal Floor Decking Roll Forming Machine is used to produce metal floor decks which are widely used in steel buildings. Main components of this machine are decoiler, guiding and leveling device, roll former, hydraulic cutting device, collecting table, hydraulic station, etc. Fully automatically controlled by PLC and operated by touch screen, the machine enjoys high forming speed and makes little noise.

    Technical Parameters - YX65-225-675
    Raw MaterialCarbon Steel, Galvanized Steel, Q235
    Material Thickness0.8-1.5mm
    Material WidthDepend on specific profile
    Diameter of Shaft120mm
    Material of Shaft45# steel
    Material of Rolls

    GCr15 Over quenching HRC 58-62°

    Main Power11KW*2
    Forming Speed15-20m/min
    Forming Station24-32 stations
    Cutting TypeHydraulic cutting
    Cutting Blade

    Cr12 Mov
